Adapter Tech
| Series... | Datasheet | Power | Input Range | Outputs | Dimensions | Features |
ATS005A2-F
|
5 | 100-240 | Single | 37.5x28x21 | I.T.E. Power Module | |
|
ATS012A3-F
|
12 | 100-240 | Single | 37.5x28x21 | I.T.E. Power Module | |
ATM012T-F
|
12 | 100-240 | Single | 65x44.7x24 | I.T.E./ Medical Open Frame | |
ATM024T-F
|
24 | 100-240 | Single | 70x48x26 | I.T.E./ Medical Open Frame | |
ATM024T-F
|
24 | 100-241 | Single | 89x51x24 | I.T.E./ Medical Open Frame | |
ATM065A4-F
|
65 | 100-240 | Single | 76x51x24 | I.T.E./ Medical Open Frame | |
ATM065T-F
|
65 | 100-240 | Single | 102x51x31 | I.T.E./ Medical Open Frame | |
ATM130A5-F
|
100 | 100-240 | Single | 50.8x76.2x29.6 | I.T.E./ Medical Open Frame | |
ATM120T-F
|
120 | 100-240 | Single | 127x76x31 | I.T.E./ Medical Open Frame | |
ATM200TS-F
|
140 | 100-240 | Single | 101.6x50.8x36 | I.T.E./ Medical Open Frame | |
ATM200TS-F
|
140 | 100-241 | Single | 103.4x62x42.9 | I.T.E./ Medical Open Frame | |
ATM150T-F
|
150 | 100-240 | Single | 127x76x38 | I.T.E./ Medical Open Frame | |
ATM200A5-F
|
150 | 100-240 | Single | 50.8x76.2x39.1 | I.T.E./ Medical Open Frame | |
ATM210T-F
|
160 | 100-240 | Dual | 127x76x38 | I.T.E./ Medical Open Frame | |
ATM200T-F
|
200 | 100-240 | Single | 127x76x38 | I.T.E./ Medical Open Frame | |
ATM300A5-F
|
200 | 100-240 | Single | 101.6x50.8x40.6 | I.T.E./ Medical Open Frame | |
ATM305T-F
|
255 | 100-240 | Dual | 127x76x38 | I.T.E./ Medical Open Frame | |
ATM450S-F
|
260 | 100-240 | Dual | 127x76x34 | I.T.E./ Medical Open Frame | |
ATM450S-F
|
260 | 100-241 | Dual | 127x87x50 | I.T.E./ Medical Open Frame | |
ATM450S-F
|
260 | 100-242 | Dual | 127x87x50 | I.T.E./ Medical Open Frame | |
ATM450S-F
|
260 | 100-243 | Dual | 148x80x41 | I.T.E./ Medical Open Frame | |
ATM500A5-F
|
300 | 100-240 | Single | 127x76.2x38.1 | I.T.E./ Medical Open Frame | |
ATM600A5-F
|
400 | 100-240 | Single | 127x76.2x38.6 | I.T.E./ Medical Open Frame | |
ATM600-F
|
600 | 100-240 | Single | 203x127x40 | I.T.E./ Medical Open Frame | |
|
ATM750A5-F
|
750 | 100-240 | Single | 203x127x40 | I.T.E./ Medical Open Frame | |
ATM1000A5-F
|
1000 | 100-240 | Single | 239x140.5x50 | I.T.E./ Medical Open Frame |
| Series... | Datasheet | Power | Input Range | Outputs | Dimensions | Features |
German Medical Product Law (MPG)
|
Download » | 0 | 230V - Version: 196 – 264 VAC; 110V - Version: 95 – 135 VAC | 230V: 9V, 110V: 0-30V | 85 x 100 x 50mm | Chassis |
Telephone Exchange 3192
|
Download » | 0 | 20 – 60 VDC | -5V, -12V, 5V, 12V | 109.3 x 92.42mm | Open Frame, Enclosed, U-Chassis |
AUX-PSU
|
Download » | 0 | 93 - 260 VAC | 48V | Open Frame | |
Banking Systems
|
Download » | 0 | 90 – 264 VAC | The power supply provides multiple switchable DC-outputs, which can customized according to the specific requirement. | 55mm–65mm x 240mm–400mm x 200–300mm | Open Frame, Enclosed |
Arch Electronics
| Series... | Datasheet | Power | Input Range | Outputs | Dimensions | Features |
AES60U
|
Download » | 60 | 90-264 VAC or 120-370 VDC | Single | 4.13 x 2.28 x 1.5 In 105.0 x 58.0 x 38.1 mm |
U Bracket |
AES60E
|
Download » | 60 | 90-264 VAC or 120-370 VDC | Single | 4.13 x 2.28 x 1.5 In 105.0 x 58.0 x 38.1 mm |
Enclosed Frame |
AES60O
|
Download » | 60 | 90-264 VAC or 120-370 VDC | Single | 4.1 x 2.05 x 1.0 In 103.9 x 52.1 x 25.4 mm |
Open Frame |
SZA60U Series
|
Download » | 60 | 90-264 VAC or 120-370 VDC | Single | 3.15 x 2.26 x 1.5 In 80.0 x 57.5 x 38.0 mm |
Open Frame Switching Power Supply, Universal Input: 90 - 264 VAC, Single Ouput , <0.3W No Load Input Power, 5 VDC to 48 VDC Output, 3000 VAC Input to Output Isolation, Ultra Compact Size, 3- Years Product Warranty |
SZA60O Series
|
Download » | 60 | 90-264 VAC or 120-370 VDC | Single | 3.0 x 2.0 x 1.24 In 76.3 x 50.6 x 31.5mm |
Open Frame Switching Power Supply, Universal Input: 90 - 264 VAC, Single Ouput , <0.3W No Load Input Power, 5 VDC to 48 VDC Output, 3000 VAC Input to Output Isolation, Ultra Compact Size, 3- Years Product Warranty |
SZA100 Series
|
Download » | 100 | 85- 265 | Single Output | 4.05 x 2.04 x 1.36 Inches ( 102.75 x 51.7 x 34.5 mm ) Tolerance ±0.5mm | Open Frame Switching Power Supply, Universal Input : 85-265 VAC, Single Output, <0.3w No Load Input Power (48Vout <0.5W), 12VDC to 48 VDC Output, 3000 VAC input to Output Isolation, Ultra Compact Size, 3- Years Prduct Warranty |
AQF100O
|
Download » | 100 | 90-264 VAC or 120-370 VDC | Single | 4.1 x 2.05 x 0.98 In 103.9 x 52.1 x 25.0 mm |
AC/DC Power Supply, Open Frame |
AQF100C
|
Download » | 100 | 90-264 VAC or 120-370 VDC | Single | 4.1 x 2.05 x 0.98 In 103.9 x 52.1 x 25.0 mm |
AC/DC Power Supply, Open Frame |
AQF120O
|
Download » | 120 | 90-264 VAC or 100-370 VDC | Single | 5.0 x 3.0 x 1.16 In 127.0 x 76.2 x 29.5 mm |
Open Frame |
AQF120U
|
Download » | 120 | 90-264 VAC or 100-370 VDC | Single | 5.0 x 3.24 x 1.5 In 127.0 x 82.2 x 38.1 mm |
U Bracket |
AQF120E
|
Download » | 120 | 90-264 VAC or 100-370 VDC | Single | 5.0 x 3.24 x 1.5 In 127.0 x 82.2 x 38.1 mm |
Enclosed Frame |
AQF160
|
Download » | 160 | 90-264 VAC or 120-370 VDC | Single | 4.1 x 2.05 x 1.42 In 103.9 x 52.1 x 29.0 mm |
Open Frame |
|
AQF120U-180W
|
Download » | 180 | 90-264 90-264 VAC or 120-370 VDC (80-274 VAC or 110-390 VDC with Derating)VAC or 100-370 VDC | Single | 5.0 x 3.24 x 1.5 In 127.0 x 82.2 x 38.1 mm |
U Bracket |
|
AQF120E-180W
|
Download » | 180 | 90-264 VAC or 100-370 VDC | Single | 5.0 x 3.24 x 1.5 In 127.0 x 82.2 x 38.1 mm |
Enclosed Frame |
ARFV240
|
Download » | 240 | 90~264VAC | 12, 24, 48 VDC | 4.02 x 2.05 x 1.09 Inches | |
AQF240E
|
Download » | 240 | 90-264 VAC or 120-370 VDC | Single | 6.0 x 4.18 x 1.38 In 150.0 x 106.0 x 35.0 mm |
AC-DC Enclosed Frame |
AQF240U
|
Download » | 240 | 90-264 VAC or 120-370 VDC | Single | 5S:6.0 x 4.18 x 1.46 In, 150.0 x 106.0 x 35.0 mm Others:6.0 x 4.18 x 1.38 In, 150.0 x 106.0 x 35.0 mm |
AC-DC U Bracket |
AQF360E
|
Download » | 360 | 90-264 VAC or 120-370 VDC | Single | 6.8 x 3.2 x 2.1 In 172.7 x 81.3 x 53.3 mm |
AC-DC Enclosed Frame |
AQF360F
|
Download » | 360 | 90-264 VAC or 120-370 VDC | Single | 7.8 x 3.2 x 1.57 In 197.7 x 81.3 x 40.0 mm |
AC-DC Enclosed Frame |
AQF360U
|
Download » | 360 | 90-264 VAC or 120-370 VDC | Single | 6.8 x 3.2 x 1.5 In 172.7 x 81.3 x 38.0 mm |
AC-DC U Bracket |
AQFC480F
|
Download » | 480 | 90-264 VAC or 120-370 VDC | Single | 7.98 x 4.2 x 1.78 In 202.8 x 106.5 x 45.0 mm |
AC/DC Power Supply Enclosed |
AQFV480E
|
Download » | 480 | 90-264 VAC or 120-370 VDC | Single | 7.0 x 4.2 x 2.37 In 177.8 x 106.5 x 60.3 mm |
AC/DC Power Supply Enclosed |
AQFC480E
|
Download » | 480 | 90-264 VAC or 120-370 VDC | Single | 7.0 x 4.2 x 2.37 In 177.8 x 106.5 x 60.3 mm |
AC/DC Power Supply Enclosed |
AQFV480F
|
Download » | 480 | 90-264 VAC or 120-370 VDC | Single | 7.98 x 4.2 x 1.78 In 202.8 x 106.5 x 45.0 mm |
AC/DC Power Supply Enclosed |
AQFC480U
|
Download » | 480 | 90-264 VAC or 120-370 VDC | Single -12V / 24V / 36V / 48V | 7.0 x 4.2 x 1.78 Inches (177.8 x 106.5 x 45.0 mm ) Tolerance ±0.5 mm | AC/DC Power Supply U Bracket |
AQF600
|
Download » | 600 | 90-264 VAC or 120-370 VDC | Single | 9.0 x 4.13 x 1.72 Inches (228.5 x 105 x 44 mm) | AC/DC Power Supply Enclosed |
Cincon
| Series... | Datasheet | Power | Input Range | Outputs | Dimensions | Features |
EC2SANH.pdf
|
Download » | 2 | 4.5~5.5V | 5V | 0.77x0.28x0.40(SIP7) | EC2SANH SERIES 2WATT, UNREGULATED OUTPUT DC-DC CONVERTERS |
CFM04S
|
Download » | 4 | 85-305 | 3.3V | 1.56x0.764x0.720 | Switching Power Supplies AC-DC Module ITE, 4Watt, Open Frame, 90-264VAC Input, 3.3VDC Output |
CFM06S
|
Download » | 6 | 90-264 | 3.3V | 1.555x0.764x0.720 | Switching Power Supplies AC-DC Module, 6Watt, Open Frame, 90-264VAC Input, 3.3VDC Output |
CFM12S
|
Download » | 12 | 90-264 | 5V | 1.500x1.000x0.764 | Switching Power Supplies AC-DC Module, 12 Watt, Open Frame, 90-264VAC Input, 5VDC Output |
TR18RDM.pdf
|
Download » | 18 | 80-264 | 5V | 3.165x1.693x1.453 | Wall Mount Medical AC Adapters Switching Adapter, Level VI, Wallmount, 18Watt |
CFM20S
|
Download » | 20 | 90-264 | 5V | 2.382x1.300x0.906 | Switching Power Supplies AC-DC Module ITE, 20Watt, Open Frame, 90-264VAC Input, 5VDC Output |
CFM21
|
Download » | 20 | 90-264 | 3.3V | 2.38x1.60x0.80 | Switching Power Supplies AC-DC Module, 20 Watt, Single Output, 90-264VAC Input, 3.3VDC Output |
CFM25S
|
Download » | 25 | 90-264 | 5V | 2.000x1.100x0.980 | Switching Power Supplies AC-DC Power Supply, Open Frame, 25 Watt, Single Output, 5VDC Output, 4.0A, 81% Efficiency, PCB |
TR30RDM
|
Download » | 30 | 80-264 | 5V | 3.807x2.283x1.703 | Wall Mount Medical AC Adapters Switching Adapter, Level VI, Wallmount, 30 Watt, 90-264VAC Input, 5VDC Output, US, 5.5x2.1x12mm, Straight, DC Cable 1220MM, WITH CHANGEABLE PLUGS |
CFM36S
|
Download » | 36 | 90-264 | 5V | 3.00x1.50x1.100 | Switching Power Supplies AC-DC Module ITE, 36Watt, Open Frame, 90-264VAC Input, 5VDC Output Class I, Wafer Type. |
CFM40C.pdf
|
Download » | 40 | 90-264 | 3.3V | 5.433x2.323x1.894 | DIN Rail Power Supplies DIN Rail Power Supply, Single Output, 40 Watt, 90-264VAC Input, 3.3VDC Output, 6A, 50mV Ripple & Noise, 70% Efficiency |
CFM40D-T.pdf
|
Download » | 40 | 90-264 | 5V/12V | 4.000x2.000x1.200 | Switching Power Supplies AC-DC Module, 40 Watt, Dual Output, Open Frame, 90-264VAC Input, 5VDC(V1), 12VDC(V2) Output |
CFM40M
|
Download » | 40 | 90-264 | 3.3V | 3.000x2.000x0.948 | 40Watts AC-DC 2"x3" Medical & ITE Open Frame Power Supply |
CFM40S.pdf
|
Download » | 40 | 90-264 | 3.3V | 4.000x2.000x1.275 | Switching Power Supplies AC-DC Module, 40 Watt, Open Frame, 90-264VAC Input, 3.3VDC Output |
CFM41S.pdf
|
Download » | 40 | 90-264 | 5V | 2.000x2.000x1.01 | 40Watts AC-DC 2"x2" ITE Open Frame Power Supply with Peak Load |
CFM50S
|
Download » | 50 | 90-264 | 5V | 3.000x2.000x1.067 (Wafer), 3.00x2.00x1.142 (PCB Mount), 3.60x2.52x1.358 (Cover), 3.14x2.17x1.201 (Encapsulated), 4.20x2.17x1.201 (Terminal Block), 4.20x2.17x1.783 (Din rail type) | 50Watts AC-DC 2"x3" ITE Open Frame Power Supply, 85~264Vac Input 5Vdc Output, Wafer |
CFM60T
|
Download » | 60 | 90-264 | 5V/12V/-12V | 4.000x2.000x1.260 | Switching Power Supplies AC-DC Module, 60 Watt, Triple Output, 90-264VAC Input, 5VDC(V1), 12VDC(V2), -12VDC(V3) Output |
CFM60S
|
Download » | 60 | 90-264 | 3.3V | 4.000x2.000x1.275 | Switching Power Supplies AC-DC Module, 60 Watt, Open Frame, 90-264VAC Input, 3.3VDC Output |
CFM60M
|
Download » | 60 | 90-264 | 5V | 4.000x2.000x1.100 | Switching Power Supplies AC-DC Module, Medical, 60 Watt, Open Frame, 90-264VAC Input, 5VDC Output |
CFM60C.pdf
|
Download » | 60 | 90-264 | 3.3V | 5.433x2.323x1.894 | DIN Rail Power Supplies DIN Rail Power Supply, Single Output, 60 Watt, 90-264VAC Input, 3.3VDC Output, 8A, 50mV Ripple & Noise, 72% Efficiency |
CFM61S
|
Download » | 60 | 90-264 | 5V | 2.00x2.00x1.398 | Switching Power Supplies AC-DC Module, 60 Watt, Open Frame, 90-264VAC Input, 5VDC Output |
CFM70S
|
Download » | 70 | 85-264 | 5V | 3.000x2.000x1.067 (Wafer), 3.00x2.00x1.142 (PCB Mount), 3.60x2.52x1.358 (Cover), 3.14x2.17x1.201 (Encapsulated), 4.20x2.17x1.201 (Terminal Block), 4.20x2.17x1.783 (Din rail type) | 70Watts AC-DC 2"x3" ITE Open Frame Power Supply, 85~264Vac Input 5Vdc Output, Wafer |
CFM80S.pdf
|
Download » | 80 | 90-264 | 5V | 4.000x2.000x1.142 | 80 WATT OPEN FRAME AC-DC MODULES |
CFM81S
|
Download » | 80 | 90-264 | 12V | 3.000x2.000x1.339 (Wafer), 3.000x2.000x1.413 (PCB Mount), 3.200x2.441x1.575 (Cover) | 80Watts AC-DC 2"x3" ITE Open Frame Power Supply with Peak Load |
CFM150S
|
Download » | 120 | 90-264 | 12V | 4.00x2.00x1.283 | AC-DC MODULE CFM150S120 |
CFM130S
|
Download » | 130 | 80-264 | 12V | 3.000x2.000x1.20 (Open-frame), 3.598x2.000x1.299 (Base Cooling), 3.598x2.520x1.358 (Cover) | AC-DC MODULE CFM130S120 |
CFM130M
|
Download » | 130 | 80-264 | 12V | 3.000x2.000x1.20 | Switching Power Supplies AC-DC Module with PFC, Medical, MEET 2 MOPP, 130 Watt, Open Frame, 80-264VAC Input, 12VDC Output |
TR160M
|
Download » | 160 | 80-264 | 12V | 5.906x2.756x1.496 | MEDICAL ADAPTER AC-DC TR160MA120-1446E471 VI |
LFM200S
|
Download » | 200 | 85-264 | 12V | Baseplate:3.04x2.00x1.00 Covered:3.09x2.28x1.00 | Switching Power Supplies AC-DC Switching Power Module, 90-264VAC Input, 200W, 12V output |
CFM202S
|
Download » | 200 | 90-264 | 12V | 4.000x2.000x1.311 (Baseplate), 4.598x2.520x1.358 Inches (Covered ) | 200W AC-DC OPEN MODULE WITH 12V OUTPUT |
TR220M
|
Download » | 220 | 80-264 | 12V | 7.087x2.953x1.752 | 220Watts AC-DC Medical C8/C14 Desktop Power Adapter, Class I, 12Vdc Output, Din Power Plug Molded Type |
CFM260S
|
Download » | 260 | 85-264 | 12V | 4.000x2.000x1.441 | AC-DC MODULE CFM260S120 |
CFM300S
|
Download » | 300 | 90-264 | 12V | 5.000x3.000x1.421 | Switching Power Supplies AC-DC Power Supply with PFC, ITE & Industrial, 300 Watt, Non-Covered, 12VDC Output, 1A, 120mV |
CFM300M
|
Download » | 300 | 90-264 | 12V | 5.000x3.000x1.421 | Switching Power Supplies AC-DC Power Supply with PFC, Medical, 300 Watt, Non-Covered, 12VDC Output, 25A, 120mV |
LFM300M
|
Download » | 300 | 85-264 | 12V | Baseplate:4.04x2.00x1.00 Covered:4.09x2.28x1.00 | Switching Power Supplies AC-DC Switching Power Module, 90-264VAC Input, 300W, 12V output |
LFM300S
|
Download » | 300 | 85-264 | 12V | Baseplate:4.04x2.00x1.00 Covered:4.09x2.28x1.00 | Switching Power Supplies AC-DC Switching Power Module, 90-264VAC Input, 300W, 12V output |
CFM400S
|
Download » | 400 | 80-264 | 12V | 5.000x3.000x1.540 | Switching Power Supplies AC-DC Module ITE, 400Watt, Open Frame, 80-264VAC Input, 12V DC Output |
LFM420M
|
Download » | 420 | 85-264 | 12V | Baseplate:5.00x3.00x1.00 Covered:5.09x3.29x1.00 | Switching Power Supplies AC-DC Switching Power Module, 90-264VAC Input, 400W, 12V output |
LFM420S
|
Download » | 420 | 85-264 | 30V | Baseplate:5.00x3.00x1.00 Covered:5.09x3.29x1.00 | Switching Power Supplies AC-DC Switching Power Module, 90-264VAC Input, 400W, 30V output |
CFM500S
|
Download » | 500 | 80-264 | 12V | 5.000x3.000x1.540 | AC-DC MODULE CFM500S120 |
CFM500M
|
Download » | 500 | 80-264 | 12V | 5.000x3.000x1.540 | MEDICAL OPEN FRAME AC-DC CFM500M120 |
Cotek
| Series... | Datasheet | Power | Input Range | Outputs | Dimensions | Features |
MP05 Series
|
Download » | 5 | 85-264 VAC, 125-373 VDC | Single | 2.3 x 1.8 x 0.75 | Green Design, No-Load Power Consumption < 0.3W, Universal AC Input/Full Range, Medical Safety Approved |
MP10 Series
|
Download » | 10 | 85-264 VAC, 125-373 VDC | Single | 2.5 x 1.9 x 0.9 inches | Green Design, No-Load Power Consumption < 0.3W, Universal AC Input/Full Range, Medical Safety Approved |
MP15 Series
|
Download » | 15 | 85-264 VAC, 125-373 VDC | Single | 2.75 x 1.9 x 0.9 inches | Green Design, No-Load Power Consumption < 0.3W, Universal AC Input/Full Range, Medical Safety Approved |
MP20 Series
|
Download » | 20 | 85-264 VAC, 125-373 VDC | Single | 3.5 x 2.0 x 0.75 inches | Green Design, No-Load Power Consumption < 0.3W, Universal AC Input/Full Range, Medical Safety Approved |
GE25 Series
|
Download » | 25 | 88-264 VAC, 125-373 VDC | Single | 3.11 x 2.0 x 1.1 inches | Green design, No-load power consumption <0.5W, Cooling by free air convection, High efficiency, long life and high reliability |
GE35 Series
|
Download » | 35 | 88-264 VAC, 125-373 VDC | Single | 3.9 x 3.2 x 1.4 inches | Green design, No-load power consumption <0.5W, Cooling by free air convection, High efficiency, long life and high reliability |
MP45 Series
|
Download » | 45 | 90-264 VAC, 127-370 VAC | Single | 2.0 x 1.14 x 4.0 inches | Green Design, No-Load Power Consumption < 0.5W, Universal AC Input/Full Range, Medical Safety Approved |
MP45 Series Dual Output
|
Download » | 45 | 90-264 VAC, 127-370 VAC | Dual | 2.0 x 1.14 x 4.0 inches | Green Design, No-Load Power Consumption < 0.5W, Universal AC Input/Full Range, Medical Safety Approved |
GE50 Series
|
Download » | 50 | 88-264 VAC, 125-373 VDC | Single | 3.9 x 3.2 x 1.4 inches | Green design, No-load power consumption <0.5W, Cooling by free air convection, High efficiency, long life and high reliability |
MP60 Series
|
Download » | 60 | 90-264 VAC, 127-370 VAC | Single | 4.0 x 2.0 x 1.14 | Green Design, No-Load Power Consumption < 0.5W, Universal AC Input/Full Range, Medical Safety Approved |
MP60 Series Dual Output
|
Download » | 60 | 90-264 VAC, 127-370 VAC | Dual | 4.0 x 2.0 x 1.14 | Green Design, No-Load Power Consumption < 0.5W, Universal AC Input/Full Range, Medical Safety Approved |
AK75 Series
|
Download » | 75 | 90-264 VAC, 127-370 VDC | Single | 6.18 x 3.86 x 1.65 inches | Green Design, No-Load Power Consumption <0.7W, Cooling By Free Air Convection, High Efficiency, Long Life and High Reliability |
GE75 Series
|
Download » | 75 | 88-264 VAC, 125-373 VDC | Single | 0.2 x 0.15 x 0.06 inches | Green design, No-load power consumption <0.5W, Cooling by free air convection, High efficiency, long life and high reliability |
QE75 Series
|
Download » | 75 | 90-264 VAC, 127-373 VAC | Dual | 5.07 x 3.8 x 1.5 inches | Universal AC Input/Full Range, Auto Switch When Power Off, Built-In Constant Current Limiting Circuit |
QP75 Series
|
Download » | 75 | 90-264 VAC, 127-370 VAC | Dual | 5.07 x 3.8 x 1.5 inches | Universal AC Input/Full Range, Auto Switch When Power Off, Built-In Constant Current Limiting Circuit |
QP100 Series
|
Download » | 100 | 90-264 VAC, 127-370 VAC | Dual | 5.07 x 3.8 x 1.5 inches | Universal AC Input/Full Range, Auto Switch When Power Off, Built-In Constant Current Limiting Circuit |
QE100 Series
|
Download » | 100 | 90-264 VAC, 127-373 VAC | Dual | 5.07 x 3.8 x 1.5 inches | Universal AC Input/Full Range, Auto Switch When Power Off, Built-In Constant Current Limiting Circuit |
AK100 Series
|
Download » | 100 | 90-264 VAC, 127-370 VDC | Single | 6.18 x 3.86 x 1.65 inches | Green Design, No-Load Power Consumption <0.5W, Cooling By Free Air Convection, High Efficiency, Long Life and High Reliability |
GE100 Series
|
Download » | 100 | 88-264 VAC, 125-373 VDC | Single | 5.07 x 3.9 x 1.5 inches | Green design, No-load power consumption <0.5W, Cooling by free air convection, High efficiency, long life and high reliability |
AK150 Series
|
Download » | 150 | 90-264 VAC, 127-370 VDC | Single | 7.76 x 4.86 x 1.65 inches | Green Design, No-Load Power Consumption <0.7W, Cooling By Free Air Convection, High Efficiency, Long Life and High Reliability |
UP150 Series
|
Download » | 150 | 90-264 VAC, 127-370 VAC | Single | 7.8 x 2.7 x 1.3 inches | Universal AC Input/Full Range, Built-In Active PFC Function, PF > 0.9, User Adjustable Output Voltage/Constant Current Level |
MP150 Series
|
Download » | 150 | 90-264 VAC, 127-373 VAC | Single | 2.0 x 1.26 x 4.0 inches | Universal AC Input/Full Range with Act PFC, Medical Safety Approvals, High Operation Temperature |
AP150 Series
|
Download » | 150 | 90-264 VAC, 127-370 VDC | Single | 2.4 x 1.0 x 6.9 inches | Universal AC Input/Full Range, Built In Active PFC Function. PF > 0.90, No Load Power Consumption < 1W, User Adjustable Output Voltage and Constant Current Level |
GE150 Series
|
Download » | 150 | 88-264 VAC, 125-373 VDC | Single | 7.04 x 3.9 x 1.5 inches | Green design, No-load power consumption <1W, Cooling by free air convection, High efficiency, long life and high reliability |
QE155 Series
|
Download » | 155 | 90-264 VAC, 127-373 VAC | Dual | 5.07 x 3.8 x 1.5 inches | Universal AC Input/Full Range, Auto Switch When Power Off, Built-In Constant Current Limiting Circuit |
AK200 Series
|
Download » | 200 | 90-264 VAC, 127-370 VDC | Single | 7.75 x 3.8 x 1.7 inches | Green Design, No-Load Power Consumption <0.7W, Cooling By Free Air Convection, High Efficiency, Long Life and High Reliability |
UP200 Series
|
Download » | 200 | 90-264 VAC, 127-370 VAC | Single | 8.0 x 4.0 x 1.5 inches | Universal AC Input/Full Range, High Operation Temperature, Power OK Signal, U-Bracket Low Profile |
MP250 Series
|
Download » | 250 | 90-264 VAC, 127-373 VAC | Single | 3.0 x 1.43 x 5.0 inches | Universal AC Input/Full Range with Act PFC, Medical Safety Approvals, High Operation Temperature |
AK350 Series
|
Download » | 350 | 90-264 VAC, 127-370 VDC | Single | 4.134 x 1.614 x 7.835 inches | Universal AC Input/Full Range, Built In Active PFC Function. PF > 0.90, Constant Current Limit, Remote ON/OFF, Remote Sense Function |
UP350 Series
|
Download » | 350 | 90-264 VAC, 127-370 VAC | Single | 9.1 x 4.0 x 1.5 inches | Universal AC Input/Full Range, High Operation Temperature, Power OK Signal, U-Bracket Low Profile |
MP-350 Series
|
Download » | 350 | 90-264 VAC, 127-373 VAC | Single | 3.0 x 1.56 x 5.0 inches | Universal AC Input/Full Range with Act PFC, Medical Safety Approvals, High Operation Temperature |
MP-450 Series
|
Download » | 450 | 90-264 VAC, 127-373 VAC | Single | 4.0 x 1.56 x 7.0 inches | Universal AC Input/Full Range with Act PFC, Medical Safety Approvals, High Operation Temperature |
AK450 Series
|
Download » | 450 | 90-264 VAC, 127-370 VDC | Single | 4.134 x 1.614 x 7.835 inches | Universal AC Input/Full Range, Built In Active PFC Function. PF > 0.90, Constant Current Limit, Remote ON/OFF, Remote Sense Function |
UP500 Series
|
Download » | 500 | 90-264 VAC, 127-370 VAC | Single | 10.0 x 5.0 x 1.5 inches | Universal AC Input/Full Range, High Operation Temperature, Power OK Signal, U-Bracket Low Profile |
600U Series
|
Download » | 600 | 180-260VAC, 260-370VAC | Single | 11.9 x 4.1 x 2.5 inches | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
600S-N Series
|
Download » | 600 | 90 - 130 VAC, 180 - 260 VDC | Single | 11.4 x 5.0 x 2.7 | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
600S-P Series
|
Download » | 600 | 180 - 260 VAC, 260 - 370 VDC | Single | 11.4 x 5.0 x 3.0 inches | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
AK650 Series
|
Download » | 650 | 90-264 VAC, 127-370 VDC | Single | 5.000 x 1.610 x 9.803 inches | Universal AC Input with Active PFC, Programmable Output Voltage/Current, Forced Current Sharing At Parallel Operation |
800S-N Series
|
Download » | 800 | 90 - 130 VAC, 180 - 260 VDC | Single | 11.4 x 5.0 x 2.7 | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
800S-P Series
|
Download » | 800 | 180 - 260 VAC, 260 - 370 VDC | Single | 11.4 x 5.0 x 3.0 inches | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
AE800 Series
|
Download » | 800 | 90-264 VAC, 127-370 VDC | Single | 5.0 x 1.6 x 9.8 inches | Universal AC Input/Full Range, Programmable Output Voltage/Current, Power OK Signal, Forced Current Sharing at Parallel Operation |
AK1000 Series
|
Download » | 1000 | 90-264 VAC, 127-370 VDC | Single | 11.14 x 5.00 x 1.61 inches | Universal AC Input with Active PFC, Programmable Output Voltage/Current, Forced Current Sharing At Parallel Operation |
U1200 Series
|
Download » | 1200 | 180-260VAC, 260-370VDC | Single | 11.4 x 8.1 x 2.5 inches | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
ME1200 Series
|
Download » | 1200 | 90-264 VAC, 127-370 VAC | Single | 6.3 x 5.0 x 2.5 inches | Universal AC Input with Active PFC, Programmable Output Voltage/Current, Forced Current Sharing At Parallel Operation |
1K2S-P Series
|
Download » | 1200 | 180 - 260 VAC, 260 - 370 VDC | Single | 11.4 x 4.7 x 5.2 inches | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
1K2S-N Series
|
Download » | 1200 | 90 - 130 VAC, 180 - 260 VDC | Single | 11.4 x 5.0 x 5.0 inches | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
AK1500 Series
|
Download » | 1500 | 90-264 VAC, 127-370 VDC | Single | 11.02 x 5.00 x 2.50 inches | Universal AC Input with Active PFC, Programmable Output Voltage/Current, Forced Current Sharing At Parallel Operation |
U1500 Series
|
Download » | 1500 | 180-260VAC, 260-370VDC | Single | 11.4 x 8.1 x 2.5 inches | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
1K5S-N Series
|
Download » | 1500 | 90 - 130 VAC, 180 - 260 VDC | Single | 11.4 x 5.0 x 5.0 inches | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
AE1500 Series
|
Download » | 1500 | 90-264 VAC, 127-370 VDC | Single | 5.0 x 2.5 x 11.0 inches | Universal AC Input/Full Range, Programmable Output Voltage/Current, Power OK Signal, Forced Current Sharing at Parallel Operation |
1K5S-P Series
|
Download » | 1500 | 180 - 260 VAC, 260 - 370 VDC | Single | 11.4 x 4.7 x 5.2 inches | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
2K0S-P Series
|
Download » | 2000 | 180 - 260 VAC, 260 - 370 VDC | Single | 12.6 x 8.3 x 4.9 inches | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
2K0S-N Series
|
Download » | 2000 | 90 - 130 VAC, 180 - 260 VDC | Single | 12.6 x 8.3 x 5.3 inches | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
2K4S-P Series
|
Download » | 2400 | 180 - 260 VAC, 260 - 370 VDC | Single | 12.6 x 8.3 x 4.9 inches | High Reliability and Low Ripple Noise, Built-in ON/OFF Control, Programmable Output Voltage, Forced Current Sharing at Operation |
AE3000 Series
|
Download » | 3000 | 90-264 VAC, 127-370 VDC | Single | 14.04 x 5.0 x 5.0 inches | Universal AC Input/Full Range, Programmable Output Voltage/Current, Power OK Signal, Forced Current Sharing at Parallel Operation |
AEK3000 Series
|
Download » | 3000 | 90-264 VAC, 127-370 VDC | Single | 6.7 x 2.5 x 11.0 inches | Universal AC Input/Full Range, Programmable Output Voltage/Current, Power OK Signal, Forced Current Sharing at Parallel Operation |
AK3000 Series
|
Download » | 3000 | 90-264 VAC, 127-370 VDC | Single | 5.000 x 5.000 x 12.01 inches | Universal AC Input/Full Range, Programmable Output Voltage/Current, Power OK Signal, Forced Current Sharing at Parallel Operation |
Integrated Power Designs
| Series... | Datasheet | Power | Input Range | Outputs | Dimensions | Features |
SRP-25
|
Download » | 25 | 85-264 VAC | Single, Dual or Triple | 2.25 x 4.0 x 0.96 inches | Open Frame |
SRP-35A
|
Download » | 30 | 85-264 VAC | Single, Dual, Triple or Quadruple | 3"x 6"x 2" | Enclosed |
SRP-40A
|
Download » | 40 | 85-264 VAC | Sinlge, Dual, Triple, or Quadruple | 2.50 x 4.25 x 1.2 inches | Open Frame or Chassis/Cover |
SRW-45
|
Download » | 45 | 85-264 VAC | Sinlge, Dual, Triple, or Quadruple | 3 x 5 x 1.25 inches | Open Frame or Chassis/Cover |
GRN-45M Series
|
Download » | 45 | 85-264 VAC | Sinlge, Dual, Triple, or Quadruple | 2.5 x 4.25 x 1.0 inches | U Bracket or Chassis/Cover |
GRN-60S Series
|
Download » | 60 | 85-264 VAC | Single | 2.0 x 3.0 x 1.0 inches | Enclosed |
SRW-65
|
Download » | 65 | 85-264 VAC | Sinlge, Dual, Triple, or Quadruple | 4 x 6 x 1.1 inches | Open Frame or Chassis/Cover |
REL-70
|
Download » | 70 | 85-264 VAC | Single, dual, Triple, or Quadruple | 2.5 x 4.5 x 1.2 inches | Open Frame or Chassis/Cover |
GRN-80M Series
|
Download » | 80 | 85-264 VAC | Sinlge, Dual, Triple, or Quadruple | 3.0 x 5.0 x 1.0 inches | U Bracket or Chassis/Cover |
GRN-80S Series
|
Download » | 80 | 85-264 VAC | Single | 2.5 x 4.25 x 1.0 inches | Enclosed |
SRW-100
|
Download » | 100 | 85-264 VAC | Sinlge, Dual, Triple, or Quadruple | 3.3 x 5 x 1.5 inches | Open Frame or Chassis/Cover |
NXT-100
|
Download » | 100 | 85-264 VAC | Single | 2.5 x 4.5 x 1 inches | Open Frame or Chassis/Cover |
GRN-110M Series
|
Download » | 110 | 85-264 VAC | Sinlge, Dual, Triple, or Quadruple | 3.0 x 5.0 x 1.0 inches | U Bracket or Chassis/Cover |
GRN-110S Series
|
Download » | 110 | 85-264 VAC | Single | 3.0 x 5.0 x 1.25 inches | Enclosed |
REL-110
|
Download » | 110 | 85-264 VAC | Single, Dual, Triple, or Quadruple | 3 x 5 x 1.3 inches | Open Frame or Chassis/Cover |
SRW-115
|
Download » | 115 | 85-264 VAC | Sinlge, Dual, Triple, or Quadruple | 4.25 x 7 x 1.25 inches | Open Frame or Chassis/Cover |
CE-150
|
Download » | 150 | 85-264 VAC | Sinlge, Dual, Triple, or Quadruple | 4.0 x 7.0 x 1.75 inches | U Bracket or Chassis/Cover |
REL-150
|
Download » | 150 | 85-264 VAC | Single, Dual, Triple, or Quadruple | 4.2 x 7 x 1.5 inches | Open Frame or Chassis/Cover |
NXT-175
|
Download » | 175 | 85-264 VAC | Single | 3 x 5 x 1.25 inches | Open Frame or Chassis/Cover |
REL-185
|
Download » | 185 | 85-264 VAC | Single, Dual, Triple or Quadruple | 4.2 x 7 x 1.5 inches | Open Frame or Chassis/Cover |
CE-225
|
Download » | 225 | 85-264 VAC | Single, Dual, Triple or Quadruple | 4.75 x 8.0 x 2.0 inches | U Bracket |
NXT-225
|
Download » | 225 | 85-264 VAC | Single | 3.3x 5x 1.5 inches | Open Frame or Chassis/Cover |
CE-300
|
Download » | 300 | 85-264 VAC | Sinlge, Dual, Triple, or Quadruple | 4.9x 8.5x 1.95 inches | Enclosed |
NXT-325
|
Download » | 325 | 85-264 VAC | Single | 3.9 x 6 x 1.5 mm | Open Frame |
NXT-400
|
Download » | 400 | 85-264 VAC | Single | 3.9x 8x 1.5 inches | Open Frame or Chassis/Cover |
AQFV480U
|
480 | 90-264 VAC or 120-370 VDC | Single | 7 x 4.2 x 1.78 in 177.8 x 106.5 x 45.0 mm ) |
AC/DC Open Power Supply |
